Thermoplastic Composite Sheets - Neomera® NCF-6 Series

Neomera® NCF-6 organosheets are based on non-crimp fabrics, offering solutions for very specific needs, depending on the fabric style. We can offer Neomera® PA-6 organosheets based on uni-directional, quadrax and eventual other fabric styles upon demand. Our proprieraty sizing we use on our glass fiber for non-crimp fabric production is unique by offering covalent bonding to the thermoplastic matrix.

Polyamide-6 Composite Sheets - NCF-6 Series

Dany de Kock

Dany de Kock
Market Development Manager

"In combination with our wet caprolactam monomer impregnation process we can produce sheets between 1mm up to 3mm in one step, without any consolidation. This results in a stiff material with very high impact, as well as additive-free fire resistance properties."

NCF-6 Organosheets

What are NCF-6 organosheets?

Neomera® NCF-6 organosheets are semi finished products consisting of a non-crimped fabric impregnated with caprolactam creating a PA-6 matrix during the JM in-situ reaction process. The advantages of the thermoplastic matrix lie in the hot forming capability of the semi finished products and the resulting shorter process times compared to conventional thermoset fiber composites. This is of particular interest in the automotive industry with its short processing times. Frequently used fiber materials are glass, aramid and carbon. For non-crimped fabrics, the fibers can be e.g. all in 0° (uni-derectional), 0°/+45°/-45°/90° (quadrax), or any other design. Non-crimped fabrics are not woven, but are laying on top of each other, for Neomera® NCF-6 being stitched with a glass yarn, properties are defined by the fabric design. Neomera® NCF-6 organosheets are fully recyclable and due to the unique production method having a low carbon footprint.



Mingfu Zhang

Mingfu Zhang
Senior Research Manager

"Did you know that Neomera® NCF-6 organosheets provide superior loadbearing capacity because fibers in NCF fabrics can be directly aligned with load paths? NCF-6 organosheets contain layers of unidirectional fibers bonded together with stitching yarns. They offer superior strength and stiffness because of the straightness of fibers and are well suited for
demanding applications."

Documents

1ISO_700x475
Portfolio Overview
Material Card
EcoVadis 2023
Scott Coons

Scott Coons
Chief Sustainability Officer

"Johns Manville Neomera® organosheets not only have  lower embodied energy, but also provide significant weight savings that allow higher fuel efficieny for vehicles."

This could also be of interest to you

Contact us for detailed product information and support
