Residential Building Insulation

Johns Manville’s residential insulation products help maintain energy efficiency and lower heating and cooling costs, making homes more comfortable year round. Johns Manville is committed to providing the high quality products, resources, guidance and on demand support you need on the job.

Filter Products By
  • Properties
  • Construction
  • Application Areas
Perfect for hard-to-reach areas within attics, like corners, edges and around framing, Johns Manville Attic Protector® is premium blown-in fiberglass insulation.

Johns Manville Attic Protector® Formaldehyde-free™ premium blow-in fiberglass insulation offers effective thermal and acoustical performance. Installed with a portable blowing machine, it's perfect for covering hard-to-reach areas within attics and provides a more efficient installation for homeowners or remodeling professionals.

ClimatePro2 190x122

Advantages

Easy Installation: Insulates attics or spaces of all shapes and sizes without cutting or fitting.
Complete Coverage: Effective in tight spaces, areas with large amounts of cross-bridging or small gaps and voids.
Thermally Efficient: Effective resistance to heat transfer. No settling; no loss of R-value following installation.
Formaldehyde-free: Will not off-gas formaldehyde in the indoor environment.
Sound Control: Reduces sound transmission through exterior and interior walls, floor and ceiling assemblies.
Fire-Resistant: Flame Spread of 25 or less and Smoke Developed of 50 or less.
Resilient Inorganic Glass: No rotting, mildew or deterioration. Also noncorrosive to pipes, wiring and metal studs.
Superior Performance: Stable bonded glass fibers will not slump, settle or break down during normal applications.

  ASTM Standards   ASTM C764   Type I
  Flame Spread   ASTM E84   ≤ 25
  Smoke Development   ASTM E84   ≤ 50
  Critical Radiant Flux   ASTM E970    > 0.12 W/cm(0.11 Btu/ft2s)
  Water Vapor Sorption   ASTM C1104   5% or less by weight
  Odor Emission   ASTM C1304   Pass
  Corrosiveness   ASTM 665   Pass
  Fungi Resistance   ASTM C1388   Pass
  Combustion Characteristics   ASTM E136   Pass

Data Sheet

Attic Protector Blow-In B785 Data Sheet

SDS

Attic Protector Blow-In SDS
Attic Protector Blow-In SDS (ES)

Fact Sheet

Attic Protector Blow-In Fact Sheet

Certifications and Specifications

Fiberglass
Loose Fill Fiberglass EPD

Instructions

BI Attic Protector Blow-In System Machine Instructions
Attic Protector B-785 Installation Instructions

Attic Cards

Attic Protector B-785 Attic Card

Literature

Product Selector Guide
Blowing Wool Coverage Check and Easy Fix Checklist


JM Blow-In Video


JM Attic Protector Blow-In Machine Video


JM Overview Video

Available Documents

JM Formaldehyde-free™ Cavity-SHIELD™ fiberglass batts are made of long, resilient glass fibers bonded with a thermosetting resin. A wide range of thicknesses are available to provide NFPA 13 compliant passive fire protection in lieu of sprinklers for horizontal floor-ceiling cavities. Cavity-SHIELD ...

JM Formaldehyde-free™ Cavity-SHIELD™ fiberglass batts are made of long, resilient glass fibers bonded with a thermosetting resin. A wide range of thicknesses are available to provide NFPA 13 compliant passive fire protection in lieu of sprinklers for horizontal floor-ceiling cavities. Cavity-SHIELD fiberglass batts are available unfaced.

Cavity-SHIELD 190

Advantages

Noncombustible: ASTM E 136, NFPA 13 Section 9.2.1 compliant
Simple Installation: no special equipment required
Cost-effective: economical alternative to blow-in insulation
Formaldehyde-free: will not off-gas formaldehyde in the indoor environment
Sound Control: reduces transmission of sound through floor or ceiling assemblies
Fire Resistant: Flame Spread of 25 or less and Smoke Developed of 50 or less (ASTM E84), Class A1
Durable Inorganic Glass: will not rot, mildew or deteriorate and is noncorrosive to pipes, wiring and sheet metal ducts

 ASTM Standards  ASTM C665  Type I
 Flame Spread  ASTM E84  ≤ 25
 Smoke Development  ASTM E84  ≤ 50
 Water Vapor Sorption  ASTM C1104  5% or less by weight
 Odor Emission  ASTM C1304  Pass
 Corrosiveness  ASTM 665  Pass
 Fungi Resistance  ASTM C1388  Pass
 Combustion Characteristics  ASTM E136  Pass

Data Sheet

Cavity-SHIELD Data Sheet

SDS

Unfaced Fiberglass SDS
Unfaced Fiberglass SDS (ES)

Installation Instructions

Cavity-SHIELD Installation Guide



Literature

Cavity-SHIELD NFPA 13 Overview

Certifications and Specifications

Cavity-SHIELD Fiberglass
Fiberglass Batts EPD

Warranties

Limited Warranty


JM Fiberglass Video


JM Overview Video


Insulating Around Objects Video

Available Documents

Handling hard-to-reach cavities and corners with more consistent coverage, Johns Manville Climate Pro® blow-in fiberglass insulation makes installation faster and easier.

Johns Manville Climate Pro® Formaldehyde-free™ blow-in, loose-fill fiberglass insulation offers thermal and sound control along with fire resistance. One bag of Climate Pro provides 77.1 square feet of R-30 coverage. Engineered for professional use with high-volume blowing machines, it's ideal for attics, nonconforming spaces and hard-to-reach areas making the job faster and easier.

042522_JM_BI_ClimatePro_BagArtGraphic

Advantages

Easy Installation: Insulates attics or spaces of all shapes and sizes without cutting or fitting.
Complete Coverage: Effective in tight spaces, areas with large amounts of cross-bridging, or small gaps and voids.
Thermally Efficient: Effective resistance to heat transfer. No settling; no loss of R-value following installation.
Formaldehyde-free: Will not off-gas formaldehyde in the indoor environment.
Sound Control: Reduces sound transmission through exterior and interior walls, floor and ceiling assemblies.
Fire-Resistant: Flame Spread of 5 or less and Smoke Developed of 5 or less.
Resilient Inorganic Glass Fibers: No rotting, mildew or deterioration. Also noncorrosive to pipes, wiring and metal studs.
Superior Performance: Stable bonded glass fibers will not slump, settle or break down during normal applications.

  ASTM Standards   ASTM C764   Type I
  Flame Spread   ASTM E84   ≤ 5
  Smoke Development   ASTM E84   ≤ 5
  Critical Radiant Flux   ASTM E970     > 0.12 W/cm(0.11 Btu/ft2s)
  Water Vapor Sorption   ASTM C1104   5% or less by weight
  Odor Emission   ASTM C1304   Pass
  Corrosiveness   ASTM C764   Pass
  Fungi Resistance   ASTM C1388   Pass
  Combustible Characteristics   ASTM E136   Pass
  VOC Emissions   ES Section 01350   Pass

Data Sheet

JM Climate Pro B7700 Data Sheet

Installation Instructions

JM Climate Pro B7700 Install Instructions
Climate Pro B-7700 Install Instructions Spanish
Climate Pro PresSure Gauge User Guide

SDS

Climate Pro Blow-In SDS
Climate Pro Blow-In SDS (ES)

Literature

Product Selector Guide
Blowing Wool Coverage Check and Easy Fix Checklist
Blowing Wool Coverage Check and Easy Fix Checklist (ES)

Certification and Specifications

Fiberglass
Loose Fill Fiberglass EPD

Attic Cards

Climate Pro B7700 Attic Card
Climate Pro B7700 Cavity Wall (Sidewall) Application

Coverage Charts

Climate Pro B7700 Mid-Floor Coverage Chart
Climate Pro B7700 Expanded Cavity Wall Coverage
Climate Pro B7700 Expanded Attic Coverage Chart

Case Study

Sleeper House Case Study
Vision House Case Study

Best Practices for Installing JM Climate Pro®

Best Practices for Installing JM Climate Pro®

Best Practices for Installing JM Climate Pro®

Best Practices for Installing JM Climate Pro®

Best Practices for Installing JM Climate Pro®

Best Practices for Loading the Hopper

Best Practices for Loading the Hopper

Best Practices for Loading the Hopper

Best Practices for Loading the Hopper

Best Practices for Loading the Hopper

Blow-in Fiberglass Product Phases

Blow-in Fiberglass Product Phases

Blow-in Fiberglass Product Phases

Blow-in Fiberglass Product Phases

Blow-in Fiberglass Product Phases

Avoid Static When Installing Blow-in Insulation

Avoid Static When Installing Blow-in Insulation

Avoid Static When Installing Blow-in Insulation

Avoid Static When Installing Blow-in Insulation

Avoid Static When Installing Blow-in Insulation

JM Blow-In Fiberglass Solutions

JM Insulation Overview

Available Documents

Providing dust-free, itch-free installation, plastic-wrapped Johns Manville ComfortTherm® batts and rolls make projects easier to complete.

Johns Manville ComfortTherm® poly-encapsulated thermal and acoustical insulation offers R-Values up to R-30 and is available in precut batts to fit standard wall cavities or rolls for custom installation in any size of wall cavity. ComfortTherm® insulation is wrapped in plastic for dust-free, itch-free installation, and can be used in a wide variety of wood frame, engineered wood and steel frame construction applications, including new construction and retrofit.

CT_R13_15B_E002_PROD 190x122

Note: Color of product may differ based on the manufacturing location.

Advantages

Thermally Efficient: Effective resistance to heat transfer, with R-values up to R-30.
Formaldehyde-free: Will not off-gas formaldehyde in the indoor environment.
Sound Control: Reduces sound transmission through exterior and interior walls, floor and ceiling assemblies.
Fire-Resistant: Can be left exposed where building codes permit. Flame Spread of 25 or less and and Smoke Developed of 50 or less.
Resilient Inorganic Glass: No rotting, mildew or deterioration. Also noncorrosive to pipes, wiring and metal studs.
Superior Performance: Stable bonded glass fibers will not slump within the wall cavity, settle or break down during normal applications.

  ASTM Standards   ASTM C665   Type II, Class A, Category 1 or 2
  [Standard ComfortTherm is Category 1 (vapor retarder).
  ComfortTherm for hot, humid climates is Category 2
  (non-vapor retarder).]
  Flame Spread   ASTM E84   ≤ 25
  Smoke Development   ASTM E84   ≤ 50
  Water Vapor
  Permeance
  ASTM E96   0.5 Perms (29 ng/Pa-s-m2)
  Water Vapor Sorption   ASTM C1104   5% or less by weight
  Odor Emission   ASTM C1304   Pass
  Corrosiveness   ASTM 665   Pass
  Fungi Resistance   ASTM C1388   Pass

Data Sheet

ComfortTherm Data Sheet

SDS

ComfortTherm SDS
ComfortTherm SDS (ES)

Certifications and Specifications

Fiberglass
Fiberglass Batts EDP

Installation Instructions

Fiberglass Installation Instructions
Fiberglass Installation Instructions (ES)

Literature

Product Selector Guide

Warranties

Limited Warranty



Installing Wall Insulation Video



Installating in Your Attic Video



Insulating Around Objects Video



Insulating Your Crawl Space Video



JM Overview Video



Insulating Floors or Ceilings Video


JM Fiberglass Video

Available Documents

Combining fire resistance with a vapor barrier, Johns Manville FSK-25 batts are designed with a foil facer that can be left exposed where codes permit.

Johns Manville Formaldehyde-free™ FSK-25 thermal and acoustical fiberglass insulation is available in R-Values up to R-30, and is offered in precut batts to fit standard wall cavities. FSK-25 faced batts combine fire resistance with excellent vapor resistance, and can be used in a wide variety of wood frame, engineered wood and steel frame construction applications, including new construction and retrofit. FSK-25 batts are designed with a foil facer that can be left exposed where codes permit.

FSK Faced_Batts_Rev_White Background 190x122

Note: Color of product may differ based on the manufacturing location.

Advantages

Thermally Efficient: Effective resistance to heat transfer, with R-values up to R-30.
Formaldehyde-free: Will not off-gas formaldehyde in the indoor environment.
Sound Control: Reduces sound transmission through exterior and interior walls, floor and ceiling assemblies.
Fire-Resistant: Flame Spread of 25 or less and Smoke Developed of 50 or less. Can be left exposed where building codes permit.
Resilient Inorganic Glass: No rotting, mildew or deterioration. Also noncorrosive to pipes, wiring and metal studs.
Superior Performance: Stable bonded glass fibers will not slump, settle or break down during normal applications.

  ASTM Standards   ASTM C665   Type III, Class A, Category I
  Flame Spread   ASTM E84   ≤ 25
  Smoke Development   ASTM E84   ≤ 50
  Water Vapor Permeance Facing   ASTM E96   0.05 Perms (3 ng/Pa-s-m2)
  Water Vapor Sorption   ASTM C1104   5% or less by weight
  Odor Emission   ASTM C1304   Pass
  Corrosiveness   ASTM 665   Pass
  Fungi Resistance   ASTM C1388   Pass

Data Sheet

FSK-25 Data Sheet

SDS

FSK-25 SDS
FSK-25 SDS (ES)

Literature

Product Selector Guide

Certifications and Specifications

Fiberglass
Fiberglass Batts EDP

Warranties

Limited Warranty


JM Overview Video


JM Fiberglass Video


Insulating Your Crawl Space Video


Installating in Your Attic Video


Insulating Around Objects Video


Insulating Floors or Ceilings Video


Installing Wall Insulation Video

Available Documents

For thermal and acoustical performance that lasts, Johns Manville Kraft-faced Formaldehyde-free™ fiberglass insulation is paper-faced to help control moisture in concealed applications.

Johns Manville Formaldehyde-free™ Kraft-faced thermal and acoustical insulation offers R-Values up to R-49, and is offered in precut batts to fit standard wall cavities or rolls for custom installation in any size cavity. Kraft-faced insulation is ideal for moisture control in exterior walls, reduces sound transmission through walls, ceilings and floors, and can be used in a variety of wood-framed, engineered wood and steel frame construction applications, including new construction and retrofit.

KF_R13_15B_K1241_PROD 190x122

Note: Color of product may differ based on the manufacturing location.

Advantages

Thermally Efficient: Effective resistance to heat transfer, with R-values up to R-49.
Formaldehyde-free: Will not off-gas formaldehyde in the indoor environment.
Sound Control: Reduces sound transmission through exterior and interior walls, floor and ceiling assemblies.
Resilient Inorganic Glass: No rotting, mildew or deterioration. Also noncorrosive to pipes, wiring and metal studs.
Superior Performance: Stable bonded glass fibers will not slump within the wall cavity, settle or break down during normal applications.

  ASTM Standards   ASTM C665   Type II, Class C, Category 1
  Water Vapor Permeance Facing   ASTM E96   1.0 Perms (57 ng/Pa-s-m2)
  Water Vapor Sorption   ASTM C1104   5% or less by weight
  Odor Emission   ASTM C1304   Pass
  Corrosiveness   ASTM 665   Pass
  Fungi Resistance   ASTM C1388   Pass

Data Sheet

Kraft Faced Fiberglass Data Sheet

SDS

Kraft Faced Fiberglass SDS
Kraft Faced Fiberglass SDS (ES)

Certifications and Specifications

Fiberglass
Fiberglass Batts EDP

Installation Instructions

Fiberglass Installation Instructions
Fiberglass Installation Instructions (ES)
High Performance Unvented Attic: Install for Performance

Literature

Product Selector Guide

Warranties

Limited Warranty


JM Fiberglass Video


JM Overview Video


Insulating Your Crawl Space Video


Installating in Your Attic Video


Insulating Around Objects Video


Insulating Floors or Ceilings Video


Installing Wall Insulation Video

Available Documents

Ideal for specialty applications, Johns Manville Panel Deck FSK-25 batts are laminated with a foil facing for excellent fire resistance and a vapor barrier.

Johns Manville Panel Deck FSK-25 Formaldehyde-free™ thermal and acoustical insulation is available in R-Values up to R-30 and combines fire resistance with an excellent vapor retarder. Panel Deck FSK-25 insulation is offered in precut batts with extra-wide tabs for modular roof deck applications and other speciality commercial applications. This product is designed with a foil facer that can be left exposed where codes permit.

Panel Deck FSK-25 & PSK Faced Batts190x122

Note: Color of product may differ based on the manufacturing location.

Advantages

Thermally Efficient: Effective resistance to heat transfer, with R-values up to R-30.
Formaldehyde-free: Will not off-gas formaldehyde in the indoor environment.
Sound Control: Reduces sound transmission through exterior and interior walls, floor and ceiling assemblies.
Fire-Resistant: Flame Spread of 25 or less and Smoke Developed of 50 or less. Can be left exposed where building codes permit.
Resilient Inorganic Glass: No rotting, mildew or deterioration. Also noncorrosive to pipes, wiring and metal studs.
Superior Performance: Stable bonded glass fibers will not slump, settle or break down during normal applications.

  ASTM Standards   ASTM C665   Type III, Class A, Category I
  Flame Spread   ASTM E84   ≤ 25
  Smoke Development   ASTM E84   ≤ 50
  Water Vapor Permeance Facing   ASTM E96   0.05 Perms (3 ng/Pa-s-m2)
  Water Vapor Sorption   ASTM C1104   5% or less by weight
  Odor Emission   ASTM C1304   Pass
  Corrosiveness   ASTM 665   Pass
  Fungi Resistance   ASTM C1388   Pass

Data Sheet

Panel Deck FSK-25

SDS

Panel Deck FSK-25
Panel Deck FSK-25 (ES)

Literature

Product Selector Guide

Certifications and Specifications

Fiberglass
Fiberglass Batts EDP

Warranties

Limited Warranty

Available Documents

Easily filling gaps with no adhesive or netting, Johns Manville Spider® Plus blow-in insulation uses interlocking fiber technology to fill all gaps and voids quickly.

Johns Manville Spider® Plus Formaldehyde-free™ blow-in fiberglass insulation uses interlocking fiber technology to fill all gaps and voids quickly with no adhesive or netting for a faster installation. Spider Plus provides complete coverage, with no shrinking or settling, resulting in superior thermal performance and sound control. Designed for use in wood- and metal-frame construction, engineered- wood construction and manufactured homes.

Spider Plus 190x122

Advantages

Fast Drying: Dries immediately once installed.
Complete Coverage: Effective in tight spaces, areas with large amounts of cross-bridging or small gaps and voids.
Thermally Efficient:
Effective resistance to heat transfer, with R-values up to R-25 in a 6'' cavity.
Formaldehyde-free: Will not off-gas formaldehyde in the indoor environment.
Sound Control: Reduces sound transmission through exterior and interior walls, floor and ceiling assemblies.
Fire-Resistant: Flame Spread of 25 or less and Smoke Developed of 50 or less.
Resilient Inorganic Glass: No rotting, mildew or deterioration. Also noncorrosive to pipes, wiring and metal studs.

  ASTM Standards   ASTM C764   Type I
  Flame Spread   ASTM E84   ≤ 25
  Smoke Development   ASTM E84   ≤ 50
  Critical Radiant Flux   ASTM E970   > 0.12 W/cm(0.11 Btu/ft2s)
  Water Vapor Sorption   ASTM C1104   5% or less by weight
  Odor Emission   ASTM C1304   Pass
  Corrosiveness   ASTM 665   Pass
  Fungi Resistance   ASTM C1388   Pass
  Combustion Characteristics   ASTM E136   Pass

Data Sheet

Spider Plus Blow-In Data Sheet

SDS

Spider Plus Blow-In SDS
Spider Plus Blow-In SDS (ES)

Sell Sheet

Spider Plus Blow-In Sell Sheet



Certifications and Specifications

Spider-Plus Blow-In Fiberglass
Loose Fill Fiberglass EPD

Installation Instructions

Spider Plus Consolidated Install Instructions
Spider Plus Consolidated Install Instructions (ES)
Spider Plus Full Install Instructions
Spider Plus Full Install Instructions (ES)

Coverage Card

Spider PLUS Closed Cavities Coverage Card

Literature

Product Selector Guide

Case Study

Sleeper House Case Study


JM Blow-In Video


JM Overview Video

Available Documents

For effective management of heat flow and unwanted noise, Johns Manville Unfaced batts and rolls provide heat control from the exterior while effectively controlling noise in interior walls.

Johns Manville Formaldehyde-free™ Unfaced thermal and acoustical insulation offers R-Values of up to R-49, and is offered in precut batts to fit standard wall cavities or rolls for custom installation in any size cavity. Unfaced insulation reduces sound transmission through walls, ceilings and floors, and can be used in a variety of wood frame, engineered wood and steel frame construction applications, including new construction and retrofit.

UF_R13_15B_U1330_PROD_Shdw 190x122

Advantages

Thermally Efficient: Effective resistance to heat transfer, with R-values up to R-49.
Formaldehyde-free: Will not off-gas formaldehyde in the indoor environment.
Sound Control: Reduces sound transmission through exterior and interior walls, floor and ceiling assemblies.
Fire-Resistant: Flame Spread of 25 or less and Smoke Developed of 50 or less.
Resilient Inorganic Glass: No rotting, mildew or deterioration. Also noncorrosive to pipes, wiring and metal studs.
Superior Performance: Stable bonded glass fibers will not slump within the wall cavity, settle or break down during normal applications.

  ASTM Standards   ASTM C665   Type I
  Flame Spread   ASTM E84   ≤ 25
  Smoke Development   ASTM E84   ≤ 50
  Water Vapor Sorption   ASTM C1104   5% or less by weight
  Odor Emission   ASTM C1304   Pass
  Corrosiveness   ASTM 665   Pass
  Fungi Resistance   ASTM C1388   Pass
  Combustion Characteristics   ASTM E136   Pass

Data Sheet

Unfaced Fiberglass Data Sheet

SDS

Unfaced Fiberglass SDS
Unfaced Fiberglass SDS (ES)

Warranties

Limited Warranty

Case Studies

Rice University
Castle Pines

Installation Instructions

Fiberglass Installation Instructions
Fiberglass Installation Instructions (ES)
High Performance Unvented Attic: Install for Performance

Literature

Product Selector Guide

STC Rating Documents

Acoustical Assemblies STC Rating Reference Guide

Certifications and Specifications

Fiberglass
Fiberglass Batts EPD


JM Fiberglass Video


JM Overview Video


Insulating Your Crawl Space Video


Installating in Your Attic Video


Insulating Around Objects Video


Insulating Floors or Ceilings Video


Installing Wall Insulation Video

Available Documents

Manufactured from inorganic fibers derived from volcanic rock, Johns Manville CladStone™ Water & Fire Block Insulation is inorganic, noncombustible, moisture repellent and will not mildew or support corrosion.

Johns Manville CladStone™ Water & Fire Block insulation is manufactured from inorganic fibers derived from volcanic rock. Advanced manufacturing technology ensures consistent product quality, with high-fiber density and low shot content for excellent performance. Noncombustible, with water-repellent properties, it is ideal for exterior cavity wall and rainscreen applications. Available in 4 densities, CladStone 45 (4.5pcf), CladStone 60 (6.0 pcf), CladStone 80 (8.0 pcf) and CladStone 110 (11.0 pcf).

20171206_JM_Cladstone-084 190x122

Advantages

Water-Repellent: Repels water to ensure drainage when applied as part of a proper exterior wall cavity system.
Fire-Resistant: Melting point in excess of 2000˚F (1093˚C). Flame Spread of 0 and
Smoke Developed of 0.
Durable Inorganic Glass: No growth of fungi. No sustaining of vermin.
Densities: CladStone 45 (4.5pcf), CladStone 60 (6.0 pcf), CladStone 80 (8.0 pcf) and CladStone 110 (11.0 pcf)

  ASTM Standards   ASTM C665   Type I
  Thermal Resistance   ASTM C518   R-4.3 per inch
  Flame Spread   ASTM E84   0
  Smoke Development   ASTM E84   0
  Water Vapor Permeance Facing   ASTM E96   Unfaced, 50 perms as tested
  Water Vapor Sorption   ASTM C1104   Absorbs 0.03% by volume
  Odor Emission   ASTM C1304   Pass
  Corrosiveness   ASTM C665   Pass
  Fungi Resistance   ASTM C1338   Pass
  Combustion Characteristics   ASTM E136   Pass
      ASTM C612   Type IA, IB, II, III, IVA, IVB
     ASTM C356   Linear shrinkage < 2% 1200° F (650° C)
     ASTM C1335   Shot content less than 25%

Data Sheet

JM CladStone 45 Water & Fire Block Data Sheet
JM CladStone 60 Water & Fire Block Data Sheet
JM CladStone 80 Water & Fire Block Data Sheet
JM CladStone 110 Water & Fire Block Data Sheet
JM CladStone Retaining Clips Data Sheet

SDS

JM CladStone Water & Fire Block SDS
JM CladStone Water & Fire Block SDS (ES)

Installation Instructions

JM CladStone Water & Fire Block Installation Instructions

Specifications and Certificates

CladStone Water and Fire Block
Industrial Insulation Group (IIG) Relationship
Mineral Wool Environmental Product Declaration (Light Density)
Mineral Wool Environmental Product Declaration (Heavy Density)

Limited Warranty

Mineral Wool Limited Warranty

Literature

Product Selector Guide
Mineral Wool Product Comparison Chart
Mineral Wool 2.0 Sell Sheet
CladStone Sell Sheet

Wall Assemblies

Continuous Insulation for Rain-Screen Cladding Systems - Metal Panel
Continuous Insulation for Rain-Screen Cladding Systems - Fiber Cement Panel
Continuous Insulation for Cavity Wall Systems


JM CladStone Water & Fire Block


JM Mineral Wool


JM Mineral Wool Product Properties


JM Mineral Wool Product Properties
(short version)


JM Overview Video

JM CI and Building Science

(webinar)

Available Documents

Made from high-density, noncombustible material, Johns Manville Sound & Fire Block® mineral wool helps delay the spread of fire between interior floors and rooms.

Johns Manville Sound & Fire Block® mineral wool batts are noncombustible and moisture-resistant. The high-density fibers in mineral wool help delay the spread of fire and reduce noise transfer in interior walls and between ceilings and floors.

MineralWool_Batt_15.5x47in_3894 190x122

Advantages

Sound Control: Absorbs sound and improves wall assembly STC ratings by up to 10 dB.
Fire-Resistant: Melting point in excess of 2000˚F (1093˚C). Flame Spread of 0 and Smoke Developed of 0.
Durable Inorganic Glass: No growth of fungi. No sustaining of vermin.

  ASTM Standards   ASTM C665   Type I
  Flame Spread    ASTM E84   0
  Smoke Development   ASTM E84   0
  Critical Radiant Flux   ASTM E970   > 0.12 W/cm2 (0.11 Btu/ft2s)
  Water Vapor Sorption   ASTM C1104   5% or less by weight
  Odor Emission   ASTM C1304   Pass
  Corrosiveness    ASTM C665   Pass
  Fungi Resistance   ASTM C1338   Pass
  Combustion Characteristics   ASTM E136   Pass

Data Sheet

Sound & Fire Block Data Sheet

SDS

TempControl SDS
TempControl SDS (ES)



Limited Warranty

Mineral Wool Limited Warranty

Literature

Product Selector Guide
Mineral Wool Product Comparison Chart
Mineral Wool 2.0 Sell Sheet
MinWool Typical Sound Barrier Assemblies

Specifications and Certificates

Mineral Wool Environmental Product Declaration (Light Density)
Mineral Wool Environmental Product Declaration (Heavy Density)


JM Mineral Wool


JM Mineral Wool Product Properties


JM Mineral Wool Product Properties
(short version)


JM Overview Video

Available Documents

Designed to help delay the spread of fire, Johns Manville Mineral Wool TempControl® Batts offer thermal control for wood-stud cavities of exterior walls, basements and heated crawlspaces.

Johns Manville Mineral Wool TempControl® batts offer R-Values up to R-30. Noncombustible, fire- and moisture-resistant, they are designed to deliver thermal control and delay the spread of fire in wood-stud cavities of exterior walls, basements and heated crawlspaces.

MineralWool_Batt_15.5x47in_3894 190x122

Advantages

Thermally Efficient: Effective resistance to heat transfer with R-values up to R-30.
Fire-Resistant: Melting point in excess of 2000˚F (1093˚C). Flame Spread of 0 and Smoke Developed of 0.
Durable Inorganic Glass: No growth of fungi. No sustaining of vermin.

  ASTM Standards   ASTM C665   Type 1
  Thermal Resistance    ASTM C518   R-15, R-23, R-30
  Flame Spread    ASTM E84   0
  Smoke Development    ASTM E84   0
  Critial Radiant Flux    ASTM E970   > 0.12 W/cm2 (0.11 Btu/ft2s)
  Water Vapor Sorption    ASTM C1104   5% or less by weight
  Odor Emission    ASTM C1304   Pass
  Corrosiveness    ASTM C665   Pass
  Fungi Resistance    ASTM C1338   Pass
  Combustion Characteristics    ASTM E136   Pass

Data Sheet

TempControl Data Sheet

SDS

TempControl SDS
TempControl SDS (ES)

Installation Instructions

Mineral Wool Installation Instructions

Limited Warranty

Mineral Wool Limited Warranty

Literature

Product Selector Guide
Mineral Wool Product Comparison Chart
Mineral Wool 2.0 Sell Sheet

Specifications and Certificates

Mineral Wool Environmental Product Declaration (Light Density)
Mineral Wool Environmental Product Declaration (Heavy Density)


JM Mineral Wool


JM Mineral Wool Product Properties


JM Mineral Wool Product Properties
(short version)


JM Overview Video

Available Documents

Offering the highest yield of all JM Corbond® open-cell spray foam products, JM Corbond HY OC offers superior sprayability, improves energy efficiency, and minimizes sound transmission.

JM Corbond® High Yield Open-cell (HY OC) Spray Polyurethane Foam insulation is a two-component, low-density, E84 Class A rated, nonstructural insulation system designed for interior commercial, residential and industrial applications. JM Corbond HY OC is 100% water blown. JM Corbond HY OC offers the highest yield of any JM Corbond open-cell product. Its superior performance and exceptional sprayability make it an ideal choice for high-performing energy efficient buildings.



JM - BI - SprayFoam - OC - 0921 - 720x480
 SPF Acceptance Criteria  ASTM AC377  Pass
 Flame Spread  ASTM E84  ≤ 25
 Smoke Development  ASTM E84  ≤ 450
 Fungi Resistance  ASTM E283  Pass
 Dimensional Stability  ASTM D2126 -8.8% Change in Volume
 Core Density  ASTM D1622  0.4 pcf (normal)
 Air Permeance  ASTM E2178-03  < 0.02 (L/s)/m

DATA SHEET

JM Corbond HY OC Data Sheet
JM Corbond HY OC Data Sheet (ES)

SDS

JM Corbond SDS - A
JM Corbond SDS - A (ES)
JM Corbond HY OC SDS - B
JM Corbond HY OC SDS - B (ES)

LITERATURE

Product Selector Guide
TechConnect Sell Sheet
JM Corbond High Yield Open-Cell FAQ

INSTALLATION INSTRUCTIONS

JM Corbond High Yield Open-Cell Installation Guide
JM Corbond High Yield Open-Cell Installation Guide (ES)
SPF Processing Parameters
SPF Change-over Procedure
SPF Change-over Procedure (ES)
SPF Safety Warning Sign
SPF Health and Safety Sheet
Corbond Daily Work Log

EVALUATION REPORTS

JM Corbond OC Code Compliance Research Report (CCRR-1079)



Available Documents

Offering a high R-Value per inch, Johns Manville Corbond® III closed-cell spray polyurethane foam provides air sealing and moisture control in a single install step.

Johns Manville Corbond® III closed-cell spray polyurethane foam insulation offers and R-Value of R-7 per inch and can be applied in a single pass to a maximum of 3.5 inches, providing superior thermal performance with seamless air sealing and moisture control in a single step. Multiple immediate passes, with no wait time, may also be applied. With high yield and excellent adhesion, it's an ideal choice for high-performing energy efficient commercial, residential and industrial applications.

Resi CC SPF 223 190x122

Advantages

Complete Coverage: Expands and adheres without shrinking or settling.
Energy-Efficient: Reduces air and moisture infiltration to the building envelope and provides continuous coverage for high thermal performance.
Air Barrier: Prevents leaks when installed at 1” thickness or more.
Moisture Performance: Resists mold growth; meets current vapor retarder codes.
Wide Application Temperature Range: Can be applied between 20°F and 120°F , delivering consistent performance with seasonal versatility.
Faster Installation: Spray easily in a single pass from a minimum of .5" to a maximum of 3.5”.  Multiple immediate passes, with no wait time, may also be applied. See Data Sheet for complete information.
Commercial Approvals: NFPA 285 assembly approvals. Appendix X approval for application in unoccupied attics and crawl spaces without a prescriptive ignition barrier or coating.

  SPF Acceptance Criteria   ASTM AC377   Pass
  Flame Spread    ASTM E84   ≤ 25
  Smoke Development   ASTM E84   ≤ 450
  Fungi Resistance    ASTM C1388   Pass
  Dimensional Stability    ASTM D2126   < 15% change in volume
  Nominal Density    ASTM D1622   2 pcf
  Closed-Cell Content   ASTM D6226   > 90%
  Compressive Strength (1”)    ASTM D1621   36 psi
  Water Absorption    ASTM D2842   0.9%
  Water Vapor Transmission    ASTM E96   0.61 perms @ 1.5"
  Air Permeance    ASTM E2178-03   0.00055 (L/s)/m at 75 Pa
  Sound Transmission    ASTM E90-90, ASTM E413-87   36 (STC)

Data Sheet

JM Corbond III Data Sheet

SDS

JM Corbond SDS - A
JM Corbond SDS - A (ES)
JM Corbond Closed-cell SDS - B
JM Corbond Closed-cell SDS - B (ES)

Literature

Product Selector Guide
Exploring the Efficacy of High Lift Spray Foam Insulation White Paper
JM Spray Foam Overview Brochure
TechConnect Sell Sheet
JM Spray Foam Trial and Technical Support Brochure
JM Corbond III Seasonal FAQ
JM Spray Foam Parts and Equipment (Fusion AP)

STC Rating Documents

Acoustical Assemblies STC Rating Reference Guide

Installation Instructions

JM Corbond III SPF Installation Guide
SPF Processing Parameters
SPF Change-over Procedure
SPF Change-over Procedure (ES)
SPF Safety Warning Sign
SPF Health and Safety Sheet
Corbond Daily Work Log

Certificates

JM Corbond Re-Occupancy Certificate
JM Corbond Insulation Certificate

Spray Foam Certification

SPF Certification Overview




Technical Bulletins

JM Corbond III Air Barrier Advantage
Hybrid ccSPF + Fiberglass Wall Recommendations

Application Guides

Penetrations - Ambient Temperature
Below Grade Wall
Change in Substrate
Crawl Space
Expansion Joint
Floor Slab to Foundation Wall
Framed Floor to Foundation Wall
High Temperature Penetrations
Interstory Connections
Parapet
Substrate Joints and Defects
Unvented Attic Insulated Roof Deck
Unvented Attic Insulated Roof Deck V2
Vaulted Ceiling
Vented Attic
Wall Corner
Window Head

Evaluation Reports

Corbond III IAPMO Report
Environmental Product Declaration Spray Polyurethane Foam Insulation (HFC) Report
Life Cycle Assessment of Spray Polyurethane Foam Insulation Report

Specifications

JM Corbond III Greenguard
JM Corbond III Greenguard Gold
JM Corbond III

Case Studies

All-American House Case Study
Jay Peak Resort Case Study
Vision House Case Study

Project Profile

Denny Way Project Profile



Spray Foam Overview



SPF Changeover Procedure



AP Fusion SPF Gun Cleaning and Assembly



SPF E03 Hose Break Diagnosis



SPF E04 FTS or Thermocouple Diagnosis


JM Overview Video



What is Spray Foam? (ACC)

Available Documents

High-yield, closed-cell spray foam with HFO technology. This allows JM Corbond IV to be produced with a low Global Warming Potential (GWP) and an Ozone Depletion Potential (ODP) of zero.

JM Corbond® IV closed-cell spray polyurethane foam (SPF) is a next generation HFO blown, two-component, Class 1 rated, medium-density, SPF insulation system. JM Corbond IV is designed to insulate commercial, residential, and industrial buildings. The HFO technology allows JM Corbond IV to be produced with a low Global Warming Potential (GWP) and with an Ozone Depletion Potential (ODP) of zero. Its high yield, superior thermal and moisture performance, and exceptional sprayability and adhesion make it an ideal choice for high-performing energy efficient buildings.

JM - BI - SPF - Corbond IV - 720x480
 Flame Spread  ASTM E84  ≤ 25
 Smoke Development  ASTM E84  ≤ 450
 Fungi Resistance  ASTM C1388  Pass
 Dimensional Stability  ASTM D2126  12% change in volume
 Core Density  ASTM D1622 2.0 lb/ft3
 Closed-Cell Content  ASTM D6226  > 90%
 Compressive Strength (1")  ASTM D1621  36 psi
 Water Absorption  ASTM D2842  0.88%
 Water Vapor Transmission  ASTM E96  0.61 perm at 1.5", 1.1 perm at 1"
 Air Permeance   ASTM E2178-03  0.00055 (L/s)/m at 75 Pa
 Sound Transmission  ASTM E90-90, ASTM E413-87  36 (STC)

DATA SHEET

JM Corbond IV Data Sheet

SDS

JM Corbond SDS - A
JM Corbond SDS - A (ES)
JM Corbond IV Closed-cell SDS - B
JM Corbond IV Closed-cell SDS - B (ES)

LITERATURE

Product Selector Guide
JM Corbond IV Guide
TechConnect Sell Sheet

INSTALLATION INSTRUCTIONS

JM Corbond IV Installation Guide
SPF Processing Parameters
SPF Change-over Procedure
SPF Change-over Procedure (ES)
SPF Safety Warning Sign
SPF Health and Safety Sheet
Corbond Daily Work Log

EVALUATION REPORTS

Environmental Product Declaration Spray Polyurethane Foam Insulation (HFO) Report
JM Corbond IV IAPMO Report (ER 0146)

CERTIFICATES

JM Corbond IV Greenguard
JM Corbond IV Greenguard Gold

Project Profile

Denny Way Project Profile

Available Documents

Offering incredible yield, air isolation, R-value and acoustical performance, Johns Manville Corbond® Open-cell Spray Foam seals all voids and gaps to virtually eliminate air leakage.

Johns Manville Corbond® Open-cell Spray Foam is a lower density, nonstructural insulation that offers an R-Value of R-3.8 per inch. It delivers high yield, minimizes sound transmission and virtually eliminates any air leakage. It's designed to improve energy efficiency for a wide variety of residential, commercial and industrial applications and can act as an effective air barrier.

SF4

Advantages:

Energy-Efficient: Helps to improve energy efficiency by filling in gaps and cracks while creating an air seal.
Air Barrier: Air-impermeable at 3.75”.
Sound Transmission: Performs well acoustically when used in an assembly.
Installation: Provides high yield with superior sprayability at an exceptional value and low odor. Meets requirements for application without an ignition barrier attics and crawl spaces.

  SPF Acceptance Criteria   ASTM AC377   Pass
  Flame Spread   ASTM E84   ≤ 25
  Smoke Development   ASTM E84   ≤ 450
  Fungi Resistance   ASTM E283   Pass
  Dimensional Stability   ASTM D2126   < 15% change in volume
  Nominal Density   ASTM D1622   0.5 pcf (normal)
  Open-Cell Content    ASTM D6226   > 92%
  Water Vapor Transmission   ASTM E96   26.5 perms @ 2"
  Air Permeance   ASTM E2178-03   < 0.02 (L/s)/m
  Sound Transmission   ASTM E90-90, ASTM E413-87   38 (STC)

Data Sheet

JM Corbond oc SPF Data Sheet (US)

SDS

JM Corbond SDS - A
JM Corbond SDS - A (ES)
JM Corbond ocSPF SDS - B
JM Corbond ocSPF SDS - B (ES)

Literature

Product Selector Guide
JM Spray Foam Overview Brochure
JM Spray Foam Trial and Technical Support Brochure
TechConnect Sell Sheet
JM Corbond oc ocx Sell Sheet
JM Spray Foam Parts and Equipment (Fusion AP)

Spray Foam Certification

SPF Certification Overview

Specifications

Corbond Open-Cell

Installation Instructions

JM Corbond oc SPF Processing Parameters
JM Corbond oc SPF Processing Parameters (ES)
JM Corbond® SPF Change Over Procedure
JM Corbond SPF Change-over Procedure (ES)
JM Corbond oc SPF Installation Guide
SPF Safety Warning Sign
SPF Health and Safety Sheet
JM Corbond Re-Occupancy Certificate
JM oc SPF for Unvented Attics Insulation Certificate
Unvented Attic Hatch Guide
Corbond Daily Work Log

Evaluation Reports

Code Compliance Research Report CCRR-1079
Environmental Product Declaration Spray Polyurethane Foam Insulation (HFC) Report
Life Cycle Assessment of Spray Polyurethane Foam Insulation Report

Certificates

JM Corbond OC SPF VOC Emission Test Certificate
JM Corbond Insulation Certificate

Case Study

inSPIRE Rock Climbing Center Case Study

Project Profile

Denny Way Project Profile



Spray Foam Overview



SPF Changeover Procedure



AP Fusion SPF Gun Cleaning and Assembly



SPF E03 Hose Break Diagnosis



SPF E04 FTS or Thermocouple Diagnosis


JM Overview Video



What is Spray Foam? (ACC)

Available Documents

Johns Manville has partnered with No-Burn, Inc. to offer No-Burn® Plus ThB. This tintable white, thin film intumescent coating can be applied over JM open- and closed-cell spray polyurethane foams.

Johns Manville has partnered with No-Burn, Inc. to offer No-Burn Plus ThB. This tintable white, thin film intumescent coating can be applied over JM open- and closed-cell polyurethane foams. When exposed to high temperatures and flame it intumesces, which creates a char-barrier to reduce heat transfer and surface burning in the event of a fire. This nontoxic, water-based coating complies with IRC and IBC and can serve in lieu of otherwise code-prescribed thermal barriers.

No-Burn Plus ThB 6_88
Color Opaque/White/Tinted
Finish Flat
VOC Content 18 g/L EPA Method 24
Dry Time 60-90 minutes
Pails 5 gallons (19 L), 57.5 lbs.
Drums 55 gallons (208 L), 632.5 lbs.
Shelf Life 18 months
Cure Time 24 hours
Boiling Point 212°F
Freezing Point 32°F
% Volatile by Volume 33%
Specific Gravity 1.25

Data Sheet

JM No-Burn Plus ThB Data Sheet

SDS

JM No-Burn Plus ThB White SDS
JM No-Burn Plus ThB SDS (ES)
JM No-Burn Black Tint SDS
JM No-Burn Black Tint SDS (ES)
No-Burn Plus ThB Custom Color Tint
No-Burn Plus ThB Custom Color Tint (ES)
No-Burn Plus ThB Gray
No-Burn Plus ThB Gray (ES)
No-Burn Plus ThB Dark Charcoal
No-Burn Plus ThB Dark Charcoal (ES)

Literature

TechConnect Sell Sheet

Evaluation Report

ER-305
TER 1905-03

Certificates

Emission Test Certificate

Bulletins

Product Announcement

Available Documents

We have on-staff experts dedicated to helping you select the right parts and equipment for your spray foam rig. Our spray foam team has access to an extensive catalog of spray foam parts and equipment with overnight shipping capabilities for emergencies. You can connect with our technical service ...

We have on-staff experts designated to helping you select the right parts and equipment for your spray foam rig. Our spray foam team has access to an extensive catalog of spray foam parts and equipment with overnight shipping capabilities for emergencies.  You can connect with our technical service representative via phone, email, video calls or even text message to ensure you are ordering the correct part.  Click here for more details.

Parts_Equip_700x467

Johns Manville Vent Chutes are extruded polystyrene (XPS) sheets thermoformed to provide airflow from the soffit to the attic space when installed between insulation and the roof deck.

Johns Manville Vent Chutes are extruded polystyrene (XPS) sheets thermoformed to provide airflow from the soffit to the attic space when installed between insulation and the roof deck. Johns Manville Vent Chutes can be installed in finished or unfinished attics with open rafters in both new and retrofit construction to fit both 16" and 24" on-center cavities.

file

Advantages:

  • Adjustable: can easily be modified to fit both 16" and 24" on center cavities.
  • Venting: help optimize performance of attic insulation by minimizing wind washing, prevent blown insulation from blocking the air-flow, keep the space between soffit vents and attic space open during construction and maintain air channels over time.

JM Vent Chutes are packaged in bags of 50 vents.

Width Pieces Per Bag Bags Per Unit Net Free Airlow
48"x 22.5" 50 32 22.8 sq. in.

Data Sheet

Vent Chute Data Sheet

Available Documents

With exceptional heat, moisture and air control, Johns Manville AP™ Foil-Faced Polyiso Foam Sheathing eliminates all major thermal bridges that cause heat loss when installed correctly.

Johns Manville AP™ Foil-Faced Polyiso Foam Sheathing boards are available in R-Values up to R-28 and offer a reflective foil facer on one side and a non-reflective facer on the other. AP Foil provides exceptional heat, moisture and air control and, when installed correctly, eliminates all major thermal bridges that cause heat loss. The rigid continuous insulation board allows for maximum wall and worksite efficieny.

APFoil_LG 190x122

Advantages

Thermally Efficient: Effective resistance to heat transfer, with R-values up to R-28.
Water-Resistive Barrier: Meets the ICC-ES AC71 acceptance criteria.
Vapor Barrier: Class I vapor retarder at one inch.
Air Barrier: Meets the Air Barrier Association of America boardstock criteria, when properly installed.
Lightweight: Easy to handle and may be cut with a utility knife or saw.

  ASTM Standards   ASTM C1289   Type I, Class 1
  Flame Spread   ASTM E84   4": ≤ 25
  Smoke Development   ASTM E84   ≤ 450
  Water Vapor Transmission   ASTM E96   0.05 perms (3 ng/Pa-s-m2)
  Compressive Strength   ASTM D1621   ≥ 16 psi (110 kPa)
  Water Absorption   ASTM C209   0.1% volume
  Service Temperature      -100 to 250°F
  R-Value Per Inch     6.0

Data Sheet

AP Foil-Faced Foam Sheathing Data Sheet

SDS

AP Foil-Faced Foam Sheathing SDS
AP Foil-Faced Foam Sheathing SDS (ES)

Installation Instructions

JM Continuous Insulation Wall System Installation Guide
Technical Bulletin 302: Wall Bracing with Polyiso CI
JM AP Foil Faced Sheathing Below-Grade Interior Walls Installation Instructions
JM AP Foil Faced Sheathing Below-Grade Exterior Walls Installation Instructions
JM AP Foil Faced Sheathing Crawl Spaces Installation Instructions
AP Foil Faced Insulation Sheathing Board Attics and Cathedral/Vaulted Ceiling Installation Instructions
AP Foil Residential Installation Instructions - Above Grade Exterior Walls,Technical Guide

Technical Bulletin

JM AP Foil - NFPA 285 Wall Assemblies

STC Rating Documents

Acoustical Assemblies STC Rating Reference Guide

Wall Assemblies

Continuous Insulation for Stucco Wall Systems - Option One
Continuous Insulation for Stucco Wall Systems - Option Two
Continuous Insulation for Stucco Wall Systems - Option Three
Continuous Insulation Wall System

Continuous Insulation

Continuous Insulation Website
Technical Bulletin 301: Polyiso CI Performance in Residential Wall Applications
Technical Bulletin 303: Moisture Control with Polyiso CI
Technical Bulletin 304: Energy Efficiency with Polyiso CI

Evaluation Reports

CCRR-0444

Literature

Product Selector Guide
JM All-Purpose Wall System Sell Sheet
PIMA - Polyiso Wall Insulation Boards EPD
PIMA Performance Bulletin - Polyiso vs. XPS
JM All-Purpose Wall System Components Sheet
NFPA 285 ACM Assemblies Announcement

Certifications and Specifications

JM Continuous Insulation Wall System Specification, Section 072100 - Foil Faced Rigid Insulation
Polyiso Sheathing EPD

Case Study

JM Castle Pines Case Study
Vision House Case Study

Warranties

AP Foil and CI Max 20 Year Limited Warranty


JM Foam Board Video


JM Overview Video


JM Continuous Insulation Video


Polyiso Continuous Insulation Wall Systems: The Perfect Wall

JM CI and Building Science

(webinar)

Available Documents

Designed for easy installation in exposed interiors, Johns Manville CI Max® Polysio Foam Continuous Insulation is ideal for places where high efficiency is required.

Johns Manville CI Max® Polyiso Foam Continuous Insulation is available in R-Values up to R-26 and provides a layer of insulation to reduce thermal bridging and improve energy efficiency. CI Max Continuous Insulation is designed for exposed interior applications and is approved for use without a thermal barrier. It is suitable for wall or ceiling applications in residential, commercial, agricultural and industrial buildings.

CI_MAX_APFoil_DSCI0560_RT_CMYK 190x122

Advantages

Thermally Efficient: Effective resistance to heat transfer, with R-values up to R-26.
Vapor Barrier: Maintains a minimum thickness of one inch and qualifies as a Class I vapor retarder.
Lightweight: Easy to handle and may be cut with a utility knife or saw.

  ASTM Standards   ASTM C1289   Type I, Class 1
  Flame Spread   ASTM E84   4": ≤ 25
  Smoke Development   ASTM E84   ≤ 450
  Water Vapor Transmission   ASTM E96   0.02 perms (1.4 ng/Pa-s-m2)
  Compressive Strength   ASTM D1621   ≥ 16 psi (110 kPa)
  Water Absorption   ASTM C209   < 0.6% volume
  Service Temperature      -100 to 250°F
  R-Value Per Inch     6.0

Data Sheet

CI Max Foam Sheathing Data Sheet

SDS

CI Max Foam Sheathing SDS
CI Max Foam Sheathing SDS (ES)

Installation Instructions

CI Max for Exposed Interior Use

Warranties

AP Foil and CI Max 20 Year Limited Warranty

Literature

Product Selector Guide
PIMA - Polyiso Wall Insulation Boards EPD
PIMA Performance Bulletin - Polyiso vs. XPS
JM All-Purpose Wall System Components Sheet

Evaluation Reports

CCRR-0444

Certifications and Specifications

JM CI Max Guide Specifications in CSI Format
JM Continuous Insulation Wall System Specification, Section 072100 - Foil Faced Rigid Insulation
Polyiso Sheathing EPD


JM Foam Board Video


JM Continuous Insulation Video


JM Overview Video


Polyiso Continuous Insulation Wall Systems: The Perfect Wall

Available Documents

A rigid roof insulation board with high thermal efficiency, Johns Manville R-Panel® is compatible with multiple types of membrane systems.

Johns Manville R-Panel® rigid roof insulation board offers R-Values of up to R-23.6, providing high thermal efficiency. R-Panel is manufactured with a closed-cell polyisocyanurate foam core bonded to fiberglass-reinforced facers and designed for use over metal, nailable and non-nailable roof decks with a variety of membrane systems. R-Panel meets the International Building Code requirements for a foamed plastic roof insulation.

JM_ 100748 190x122

Advantages

Thermally Efficient: Effective resistance to heat transfer, with R-values up to R-23.6.
Universal Facer: Compatible with BUR, modified bitumen and single-ply membrane systems.
Clean Air: Meets Clean Air Act Amendments of 1990.
Miami-Dade County Product Control Approved:
Complies with the Florida Building Code including the High Velocity Hurricane Zone of the Florida Building Code.
Lightweight: Easy to handle and may be cut with a utility knife or saw.

  ASTM Standards   ASTM C1289-01   Type II, Class I, Grade 2
  Flame Spread   ASTM E84   ≤ 75
  Smoke Development   ASTM E84   ≤ 450
  Water Vapor Transmission   ASTM E96   < 1 perms (57.5 ng/Pa-s-m2)
  Compressive Strength   ASTM D1621   ≥ 20 psi (138 kPa)†
  Dimensional Stability   ASTM D2126   2% max, 7 days (length & width)
  Water Absorption   ASTM C209   < 1% volume
  Service Temperature     -100 to 250°F
  R-Value Per Inch     5.7 LTTR

Data Sheet

R-Panel Roof Insulation Data Sheet

SDS

R-Panel Roof Insulation SDS
R-Panel Roof Insulation SDS (ES)

Literature

Product Selector Guide

Available Documents
