DynaStick Cap

DynaStick Cap

Product Descriptive Name
Self-Adhering, Polyester-Reinforced, SBS Cap Sheet
Product Short Description
Self-Adhering, Polyester-Reinforced, SBS Cap Sheet
Contact Us Today
Contact Us
Contact Us Today

Product Details

DynaStick Cap

Product Long Description

Features

DynaStick Cap

Features

Meets the requirements of D6164, Type 1, Grade G

Ceramic-Coated Roofing Granules: Specifically engineered for optimal embedment in the SBS-blend sheet. The ceramic coating promotes excellent long-term adhesion.

High-Quality SBS Rubber and Asphalt Blend: Provides full recovery properties after 100% elongation and lends elasticity and flexibility to the sheet. High temperature stability top surface reduces the risk of scuffs and other damage.

Polyester-Reinforcement Mat: Polyester mat with glass-scrim reinforcement offers robust tear strength and puncture resistance, allowing for high wind performance and an excellent hail rating. The sheet also exhibits strong dimensional stability and enhanced elongation.

Self Adhering Modified Bitumen: The product’s self-adhering feature with an easy-to-peel plastic film on the bottom of the sheet allows for installation without the need of hot asphalt or heat-welding.

Reduced Fire Load: Achieves UL Class A fire ratings in certain assemblies without the need for a barrier board over combustible substrates.

Colors: White, Black, Tan, Brown, Grey, Weathered Wood, Chestnut, Red Blend, and Slate Grey

Documents

DynaStick & APPeX 4.5M SA Installation and Details

When it comes to design, we've got the tools to get you from the desk to the roof. Here you will find all of the DynaStick & APPeX 4.5M SA flashing details and fastening patterns. If you have any questions when it comes to installation, please contact our Specifier Services Group for design and your local technical representative for the field.

Drains & Vents Flashing Details*CADPDF
DSA-9 Plumbing VentDWGPDF
DSA-10 One Way Roof VentDWGPDF
DSA-11 Roof DrainDWGPDF

Expansion Joints Flashing Details*CADPDF
DSA-1 (NLB) Base Flashing for Non Load Bearing Wall - Curb to Wall E.J.DWGPDF
DSA-7 Curb Mounted Roof to Roof Expansion Joint CoverDWGPDF

Flashing Curb & Corner Flashing Details*CADPDF
DSA-8 Prefabricated CurbDWGPDF
DSA-8 (ALT) Prefabricated Curb with SkylightDWGPDF
DSA-19 Roof Hatch CurbDWGPDF

Flashing Edge Flashing Details*CADPDF
DSA-4 (GS) Roof Edge Gravel StopDWGPDF
DSA-4 (GS-ALT) Roof Edge Gravel Stop AlternateDWGPDF
DSA-4 (GTR) Roof Edge GutterDWGPDF
DSA-4 (PL) Roof Edge with Presto LockDWGPDF
DSA-4 (PT) Roof Edge with Presto TiteDWGPDF
DSA-4 (RMCF) Roof Edge with Raised Metal CantDWGPDF

Flashing Penetration Flashing Details*CADPDF
DSA-16 Roof Penetration PanDWGPDF

Flashing Wall Flashing Details*CADPDF
DSA-1 (LB) Base Flashing for Load Bearing Masonry Wall with Counter FlashingDWGPDF
DSA-2 (LB) Two Ply Base Flashing for Load Bearing Masonry Wall with Counter FlashingDWGPDF
DSA-2 Base Flashing with Surface Mounted Counter FlashingDWGPDF
DSA-3 (HW) Base Flashing for Wood Wall >24 Inches with CopingDWGPDF
DSA-3 (LW) Base Flashing for Wood Wall <24 Inches with CopingDWGPDF
DSA-6 (TH) Base Flashing for Masonry Wall >24 Inches with Coping AlternateDWGPDF
DSA-6 (TL) Base Flashing for Masonry Wall <24 Inches with Coping DWGPDF
DSA-15 Single Ply Wall Covering with Bituminous Base FlashingDWGPDF

Protection Flashing Details*CADPDF
DSA-17 Lightning Rod on Roof SurfaceDWGPDF

Tie-In Flashing Details*CADPDF
DSA-TI-01 Steep Slope to Low Slope Tie-InDWGPDF

Minimum Board Attachment Patterns

BM-18, 12, 6 DynaFast Base Sheet (18", 12", 6" O.C.)

BM-12,12,12 Mechanically Fastened Base Sheet (12", 12", 12" O.C.)

BM-18 Mechanically Fastened Base Sheet (18" O.C.)

BM-6 Mechanically Fastened Base Sheet (6" O.C.)

BM-7,7,7 Mechanically Fastened Base Sheet (7", 7", 7" O.C.)

BM-7,9,9 Mechanically Fastened Base Sheet (7", 9", 9" O.C.)

BM-75,75,75 Mechanically Fastened Base Sheet (7.5", 7.5", 7.5" O.C.)

BM-9,12,12 Mechanically Fastened Base Sheet (9", 12", 12" O.C.)

BM-9,18,18 Mechanically Fastened Base Sheet (9", 18", 18" O.C.)

BM-9,9,9 Mechanically Fastened Base Sheet (9", 9", 9" O.C.)

FA-16 Fully Adhered Cover (16-24-32)

FA-8 Fully Adhered Cover (8-16-32)

CBUA-12-6-4 Cover Board Urethane Adhesive Fastening

ICBUA-8-4-4 Insulation and Cover Board Urethane Adhesive Fastening

ICBUA-12-6-4 Insulation and Cover Board Urethane Adhesive Fastening

INUA-12-6-4 Insulation Urethane Adhesive Fastening
